SmartControl Hub – Central Control for Gym Equipment

Control bleachers, stages, curtains, and basketball systems from a single touchscreen. Safe, modular, and built on industrial-grade technology.

⚙️ What SmartControl Hub™ Does

The Smart Hub™ centralizes control for all your motorized gym equipment into one intuitive system.

Key Features

  • Controls up to 8–16 devices — bleachers, stages, curtains, backstops, and more

  • One touchscreen interface for full system control

  • Manual override (Hand/Off/Auto) for every device

  • Modular and expandable — add equipment anytime

  • Built with INDUSTRIAL-GRADE components

  • Simple installation and straightforward wiring

​

🔒 Safety-Driven by Design

Key Features

  • Hardwired Emergency Stop loop cuts all motion instantly

  • Electrical interlocks prevent simultaneous opposing motion

  • Reverse-delay timers protect motors and mechanisms

  • Meets recognized industrial control standards (UL / CSA compliant components)

​

💡 Why Choose SmartControl Hub™

Feature SmartControl Hub™ Conventional Controls
System Type Centralized touchscreen control with industrial-grade hardware core Individual wall switches or keypads
Expandable Supports up to 8 devices, easily expandable Fixed configuration, no easy expansion
Safety Hardwired E-STOP, interlocks, timed reverse blocking Basic circuit breakers, minimal interlock logic
Maintenance Affordable, transparent pricing high cost, closed ecosystem
User Interface Touchscreen with user access control, naming, grouping, and diagnostics Manual switches only, no feedback, no access control
Networking Ethernet-enabled, multiple panels networkable Standalone only
Maintenance Uses standard components, any qualified electrician can service Vendor-specific replacement parts, Factory service only

🏫 Ideal Applications

  • School gymnasiums and athletic centers

  • Community and recreation facilities

  • University sports complexes

  • Auditoriums and event halls

  • Multi-purpose venues and arenas

🧩 Expandability

Start with one Smart Hub panel that can support from 16 to 64 device relays.
Add additional hubs over Ethernet as your facility grows — each one independently or jointly controlled through a single touchscreen.

Ready to simplify and modernize your gym control system?

Name
Equipment you want to control:
Project Stage:



❓ Frequently Asked Questions — SmartControl Hub™

1. What equipment can the SmartControl Hub™ operate?

SmartControl Hub™ can control a wide range of gymnasium systems including motorized bleachers, retractable stages, divider curtains, basketball backstops, and lighting relays.
Any device that uses a low-voltage (24 V) or standard 120 V control circuit can be safely integrated.

2. Is SmartControl Hub™ compatible with our existing equipment?

Yes. SmartControl Hub™ is designed to integrate seamlessly with most existing gym control boxes.
It connects to the existing control wiring (IN/OUT or UP/DOWN) without modifying the original motor or power circuit.

3. Can multiple SmartControl Hubs be linked together?

Absolutely. Multiple SmartControl Hub panels can be networked over Ethernet, allowing a single touchscreen to coordinate multiple gyms, courts, or large facilities.
Each hub operates independently for reliability but can share data and commands across the network.

4. Does SmartControl Hub™ include manual override controls?

Yes. Each panel includes Hand-Off-Auto (HOA) selectors and local push-buttons for manual control of each device.
A hardwired Emergency Stop loop is built in to cut motion instantly, ensuring safety even if the touchscreen or PLC loses communication.

5. What safety features are built in?

SmartControl Hub™ uses several layers of safety:

  • Hardwired interlocks prevent opposite directions from engaging simultaneously.

  • Timed reverse-blocking allows motors to stop fully before reversing.

  • Emergency Stop circuit removes 24 V coil power from all relays.

  • All components are UL/CSA-recognized industrial parts, designed according to established safety standards.

6. How many devices can one SmartControl Hub™ manage?

A single SmartControl Hub panel can control up to 16 relay outputs, suitable for:

  • 8 directional devices (each requiring two relays) or

  • 16 ON/OFF devices such as lights or winches.
    For larger facilities, multiple panels can be networked together under one touchscreen interface.

7. Can SmartControl Hub™ be customized?

Yes. The system is modular and programmable, allowing you to add new devices, rename zones, or create group actions (e.g., “Retract all bleachers”).
Custom branding, interface layouts, and language options can also be provided.

8. How is SmartControl Hub™ different from other gym control systems?

Unlike closed, proprietary systems, SmartControl Hub™ uses open industrial hardware — parts any qualified electrician can service.
It’s expandable, configurable, and built for long-term support, providing unmatched value and flexibility compared to vendor-locked alternatives.

9. What’s included in a typical SmartControl Hub™ package?

  • Pre-wired control panel with Main Control Module and  Expansion modules.

  • Touchscreen HMI

  • DIN-mounted relays (up to 16 in Level 1 version)

  • 24 VDC power supply and terminal blocks

  • Full wiring diagram and installation documentation

10. How can I request a quote or learn more?

Simply fill out the Request a Quote form below.
We’ll review your facility’s setup and provide a tailored solution for your bleachers, stages, or sports equipment.
